Features
- High output 5W Osram LEDs produce a crisp, white light that we shape using precisely formed and aligned reflectors. This ensures an even distribution of light and perfectly formed spot beam for distance down the road.
- 6000°K colour temperature LED’s blend the perfect balance of white light while retaining the best possible definition and Colour Rendering Index (CRI).
- Our heavy duty stainless steel brackets are suitable for the rigours of off-road, 4WD tracks and have been finished in a durable black powder coat with white BR GEAR logos.
- Each lamp includes our innovative rubber dampening system to help isolate the housing from the bracket and reduce vibration on the electronics.
- We use a 3mm thick virtually unbreakable polycarbonate lens with hard coating for increased scratch resistance and protection from exposure to UV light.
- Our lamps are also tested and complied to ECE R10 for Electro Magnetic Compatibility (EMC), meaning you should not have any problems interfering with sensitive equipment.
- Each lamp also includes a clear see though polycarbonate cover for protection from stone spray and debris.
- Fully sealed and tested to IP68 for dust and water ingress protection, meaning they are waterproof for up to 3m of submersion. Perfectly suited for river crossings.
Beam Diagram
1 Lux at 921m (with two lamps)

Globe Application guide

LED GLOBE UPGRADE.
When searching for a simple solution to
enhance your vehicle's headlights, our
BRG LED conversion kits are your only option.
These kits are a simple Plug & Play
upgrade and are as easy as replacing
a standard factory bulb.
Technical Specifications
Specifications | LED UPGRADE KIT |
---|---|
Beam Type | High/Low Beam |
Input Voltage | 12/24V |
Current Draw 12V (single Lamp) | 1.9A |
LEDs | CREE |
Colour Temperature | 6000°K |
EMC | ECE R10 |
IP Rating | IP65 |
Raw Lumens | 5000 (Pair) |
Effective Lumens | |
Warranty | 3 Years |
What you get

BRG 9" Inch LED Driving Lights
- BR9032 9" Inch BRG LED Driving Light x2
- Big Red Gear Clear Cover
- Stainless Steel Bolts, Nuts and Washers
- Rubber Mounting Pad
- Distribution Plate
- 2 Position DT lead
- Product Instructions
Plug and Play Wiring Harness
- Plug and Play wiring harness x1
- HB3 and H4 high beam adaptor
- 12V 40A relay
- 12V rocker switch
- Product instructions
