9 Inch BRG LED Driving Light (each)

SKU BR9032

Regular price$185.00

Big Red Gear driving lights are back with better value and even more output! We’ve modified our frontrunner 9” inch BRG LED driving lights, now equipped with 30 high-output Osram LEDs for better performance. Precisely formed and aligned reflectors combine to produce crisp high-definition lights with huge capacity for illumination down the road. In fact, two lights produce a beam throw of up to 921 metres at 1 lux.

Considered design elements combine to give the 9” inch BRG LED driving lights durability and a precision look. These lights are ready for anything, whether it’s dirt tracks or river crossings. Mounted on black powder coated stainless steel brackets and fully sealed and rated to IP68 for dust and water ingress protection, these lights are built for lasting performance.

With dimensions at 220mm wide, 240mm high and 120mm deep, our 9” inch BRG LED driving lights will look comfortable on any large off-road 4x4.


  • High output 5W Osram LEDs produce a crisp, white light that we shape using precisely formed and aligned reflectors. This ensures an even distribution of light and perfectly formed spot beam for distance down the road.
  • 5700°K colour temperature LED’s blend the perfect balance of white light while retaining the best possible definition and Colour Rendering Index (CRI).
  • Our heavy duty stainless steel brackets are suitable for the rigours of off-road, 4WD tracks and have been finished in a durable black powder coat with white BR GEAR logos.
  • Each lamp includes our innovative rubber dampening system to help isolate the housing from the bracket and reduce vibration on the electronics.
  • We use a 3mm thick virtually unbreakable polycarbonate lens with hard coating for increased scratch resistance and protection from exposure to UV light.
  • Our lamps are also tested and complied to ECE R10 for Electro Magnetic Compatibility (EMC), meaning you should not have any problems interfering with sensitive equipment.
  • Each lamp also includes a clear see though polycarbonate cover for protection from stone spray and debris.
  • Fully sealed and tested to IP68 for dust and water ingress protection, meaning they are waterproof for up to 3m of submersion. Perfectly suited for river crossings.

Beam Diagram

1 Lux at 921m (with two lamps)

Technical Specifications

Input Voltage
Current Draw 12V11A
LEDs (Osram)30 x 5W
Colour Temperature5700°K
IP RatingIP68
Raw Lumens15000
Effective Lumens9056
1 Lux Distance (two lamps)921m
Warranty3 Years

What you get

  • BR9032 9" Inch BRG LED Driving Light x1
  • Big Red Gear Clear Cover
  • Stainless Steel Bolts, Nuts and Washers
  • Rubber Mounting Pad
  • Distribution Plate
  • 2 Position DT lead
  • Product Instructions
