Features
- High output 5W Osram LEDs produce a crisp, white light that we shape using precisely formed and aligned reflectors. This ensures an even distribution of light and perfectly formed spot beam for distance down the road.
- 5700°K colour temperature LED’s blend the perfect balance of white light while retaining the best possible definition and Colour Rendering Index (CRI).
- Our heavy duty stainless steel brackets are suitable for the rigours of off-road, 4WD tracks and have been finished in a durable black powder coat with white BR GEAR logos.
- Each lamp includes our innovative rubber dampening system to help isolate the housing from the bracket and reduce vibration on the electronics.
- We use a 3mm thick virtually unbreakable polycarbonate lens with hard coating for increased scratch resistance and protection from exposure to UV light.
- Our lamps are also tested and complied to ECE R10 for Electro Magnetic Compatibility (EMC), meaning you should not have any problems interfering with sensitive equipment.
- Each lamp also includes a clear see though polycarbonate cover for protection from stone spray and debris.
- Fully sealed and tested to IP68 for dust and water ingress protection, meaning they are waterproof for up to 3m of submersion. Perfectly suited for river crossings.
Beam Diagram
1 Lux at 507m (with two lamps)
Technical Specifications
Specifications | BR9012 |
---|---|
Warranty | 3 Years |
Input Voltage | 12/24V |
Current Draw 12V (single Lamp) | 3A |
LEDs (Osram) | 9 x 5W |
Colour Temperature | 5700°K |
EMC | ECE R10 |
IP Rating | IP68 |
Raw Lumens | 4500 |
Effective Lumens | 3409 |
1 Lux Distance (two lamps) | 507m |
Warranty | 3 Years |
Weight | 1.4kg (Single) |
What you get
BRG 5" Inch LED Driving Lights
- BR9012 5" Inch BRG LED Driving Light x2
- Big Red Gear Clear Cover
- Stainless Steel Bolts, Nuts and Washers
- Rubber Mounting Pad
- Distribution Plate
- 2 Position DT lead
- Product Instructions
Plug and Play Wiring Harness
- Plug and Play wiring harness x1
- HB3 and H4 high beam adaptor
- 12V 40A relay
- 12V rocker switch
- Product instructions
